Fairdale Taj 27.5″ Matte Fire Engine Red

Fairdale Taj 27.5″ Matte Fire Engine Red

“I’m excited to introduce you to my signature bike.

The Taj bike has always been about blending the tough and simple sensibilities of a BMX bike with a frame size that you can also comfortably sit down and pedal.
Frame, fork, handlebars, and cranks are all reliable chromoly.

The single-speed drivetrain and Odyssey brakes are as dependable and straightforward as they can possibly be.

I hope you’ll give it a try.”

-Taj Mihelich

Available in Matte Fire Engine Red with 27.5″ wheels.

Specs
Frame: 100% Track Certified Chromoly
Fork: 100% Chromoly. One-piece machined Steerer Tube
Handlebar: Fairdale MX-6 Bar, 100% Chromoly Steel
Stem: Sunday Freeze, Top-Load, 48mm Reach
Headset: FSA Sealed Integrated, 45º/45º
Brake Lever: Odyssey Monolever, Left and Right
Brake: Odyssey Springfield, Front and Rear
Grips: Fairdale Swan
Saddle: Fairdale Taj, Railed
Seat Post: 27.2mm
Seat Clamp: Fairdale, 30mm
Cranks: Chromoly 3-Piece, Chromoly, 175mm
Chainwheel: Fairdale, 28t
BB Parts: Mid, 19mm, Press-fit, Sealed
Pedals: Odyssey Twisted PC
Rims: Double wall, 36-Hole, Aluminum
Front Hub: 36-Hole, 3/8” Axle, Aluminum Shell, Sealed Bearing
Rear Hub: 36-Hole, 3/8” Axle, Aluminum Shell, Sealed Bearing
Tires: Maxxis Ardent Race, 27.5 x 2.2”
Chain: KMC S1
Driver: 14t Freewheel

Geometry
Size 27.5″ (60cm)
Top Tube (Effective) 616mm
Top Tube (Actual) 586mm
Seat Tube (BB Center To TT Top) 445mm
Seat Tube
(BB Center To TT Center) 405mm
Seat Tube Angle 71°
Head Tube Length 117.5mm
Head Tube Angle 71°
Chain Stay Length 437mm
Wheelbase 1067mm
Standover 766mm
Stack 547mm
Reach 428mm
Fork Length 414mm
Fork Offset 34mm
BB Drop 55mm
Dropout Spacing 110mm
BB Type Mid Press Fit
Seat Post 27.2mm
Seat Clamp 30mm
Approx. Max Tire Width 63mm
Wheel Size 27.5″
